Nominal Voltage (V)

48

Battery Capacity (AH)

100(5KWH)

150 (7.5KWH)

200(10KWH)

Working Voltage Range

42-56.25

Recommended Charging voltage (V)

52.5

Recommended Discharge cutoff Voltage(V)

45.7

Standard Charging Current (A)

50

75

100

Max Continuous Charging Current(A)

100

150

200

Standard Discharge Current (A)

50

75

100

Max Continuous Discharging Current(A)

100

150

200

Operating Temperature (℃)

-20℃~60℃ (recommend 10℃~35℃)

Cool method

Natural air cooling

Certificate

CE, UN38.3, MSDS

Cycle life

Around 5000 times

Communication

RS485(CAN optional)

Parallel function

48v support at most 15 packs in parallel use(Capacity is 75KWH)

Max size (W*D*H) mm

410*180/220*590mm(including mounting rack)

Weight

45KG

68KG

106KG

Protection Level

IP20

Communication

RS485(CAN optional)

Remark

0.5C Discharge Max: 1C, 80%DOD
